PaperAir 1000N

Avision is proud to introduce its slim scanner series. With scan size up to A4, the Avision PaperAir 1000N is your ideal tool to digitize your business document. Based on the innovative CIS (Contact Image Sensor) technology, the PaperAir 1000N is only 1.7” in height and weights a mere 1.5 kg.

Learn more

Product Details



Easy-To-Use PaperAir Manager Software

For the broader consumer who may not necessarily have any knowledge about scanner, Avision introduced the easy-to-use PaperAir Manager software without a TWAIN driver. Simply press the Scan button, the scan is completed with the predefined scan settings.  Using PaperAir you gain perhaps the easiest scanning experience that allows you to scan multiple pages no matter the size and color of your document.

Searching Document has never been easier

PaperAir Manager comes with a powerful search engine. With the advanced search engine, all documents can be scanned and all the image text can be recognized and saved into a database through the text recognition process. Simply type your keyword, your document can be searched within seconds through the recognized image text, the file name, and the tag information.

Convert paper documents into Microsoft Word/Excel/PowerPoint files

PaperAir 1000N scanner lets you automatically recognize image text and save image and the text into a Microsoft Word/Excel/PowerPoint file.

E-mail or print a scanned image directly from scanning

With PaperAir Manager, you can attach the scanned image to your default e-mail software application or print it out with your printer instead of using a copy machine.

No Power-Cord Required

The PaperAir 1000N is powered by the USB cable to the PC.  No external power adapter and cords are needed!

High Optical Resolution of 600 dpi

Despite its small footprint, the PaperAir 1000N is big on resolution. With a true optical resolution of 600 dpi, PaperAir 1000N is able to reproduce image in fine detail and subtle shade.

No Warm Up Needed and Fast Scan Speed

The LED illumination system not only saves power, it doesn’t require any warm up time.  The PaperAir 1000N is ready to go as soon as you turn it on.  It’s fast, too!  It only takes 7 seconds to scan an A4 size document.

Optimize your image with various image enhancement tools

The PaperAir Manager offers various image enhancement tools to make your scanned image ready to be used. With these features, your documents are automatically cropped, straightened, and rotated to the correct orientation, your blank pages are automatically removed, and even multi-feed can be detected to save your time to rescan.



  • Ultra slim – 1.7 inches in height and 1.8 kg (4 lbs) in weight
  • Scan size up to A4 (8.5” x 11.7”)
  • Optical resolution up to 600 dpi
  • Scans an A4-size page needs only 7 seconds (color, 300 dpi)
  • Auto resolution
  • Auto crop and straighten your image
  • High speed USB 2.0 port


▎Certification mark

Learn more


General Specification

Contact Image Sensor (CIS)

Light Source


Optical Resolution (dpi)


Max Resolutioin

216 x 297 mm ( 8.5 x 11.7 in.)

File Formats


Grayscale mode

16-bit input 8-bit output

Color mode

48-bit input 24-bit output

Memory Size


Dimensions (WxDxH)

284 x 401 x 45 mm (11.18 x 15.79 x 1.77 in.)


1.5 kg ( 3.3 lb. )


USB 2.0, ( USB 3.0 compatible )

Power Consumption

Ready < 1.5 W

Acoustical Noise

Operation < 50 dB;Ready < 45 dB

OS Support

WIN XP, Vista, Win 7, Win 8, Win 10

Bundled Software

PaperAir Manager

Scanning Speed
B/W @ 200dpi, A4

7 sec ( Include Backhome 13 sec )

B/W @ 300dpi, A4

7 sec ( Include Backhome 13 sec )

Color @ 200dpi, A4

7 sec ( Include Backhome 13 sec )

Color @ 300dpi, A4

7 sec ( Include Backhome 13 sec )

* The above specifications may vary due to computer performance and sales regions. For further details, please consult your local distributor.

▎Product Photos

High resolution Medium resolution Low resolution
11.80 MB 149.42 KB 149.42 KB

▎User Manual

PaperAir 1000NРусский886.67 KBDownload
PaperAir 1000NPortuguês841.07 KBDownload
PaperAir 1000NPolski875.86 KBDownload
PaperAir 1000N한국어1.00 MBDownload
PaperAir 1000N日本語1.12 MBDownload
PaperAir 1000NItaliano717.54 KBDownload
PaperAir 1000Nעברית1,003.29 KBDownload
PaperAir 1000NFrançais766.52 KBDownload
PaperAir 1000NEspañol772.79 KBDownload
PaperAir 1000NEnglish839.59 KBDownload
PaperAir 1000NDeutsch750.83 KBDownload
PaperAir 1000N繁體中文956.62 KBDownload
PaperAir 1000N简体中文1.05 MBDownload


PaperAir 1000NEnglish3.59 MBDownload
PaperAir 1000N繁體中文799.91 KBDownload
PaperAir 1000N简体中文778.34 KBDownload
PaperAir 1000NDeutsch662.64 KBDownload
PaperAir 1000NPortuguês739.51 KBDownload

▎Quick Guide

PaperAir 1000N简体中文1.23 MBDownload


NameVersionSizeOS SupportLink
PaperAir1000NV6.22736 MBWin XP / Vista / 7 / 8 / 10Download



  • How do I clean my Scanner?

    ▸Cleaning the Glass

    The Cleaning Procedures

    1. Moisture a piece of soft cloth with some isopropyl alcohol. (95%)

     2. Open the document cover as shown below.

    3. Gently wipe the document glass.

     4. Close the document cover. Your scanner is now ready for use.

  • ▎Software

  • Why does my scanned image always come out too dark?

    1. Please adjust the screen settings to sRGB.

    2.Please adjust the brightness settings on the screen from application software.
